LS ELECTRIC | 02040028UL | UTE100E FTU 50A 2P LO UL

Code: 02040028UL

Minimum Order Quantity: 1

Item Weight (lb): 0

US$170.75
EA
LS Electric molded case circuit breakers are UL489 listed as branch circuit protection. They are UL, CE, and CSA rated with options for Fixed and Adjustable trip for both thermal and magnetic settings as well as electronic trip.  The MCCB are available in 2 or 3 pole and range from 15 amp to 1200 amp trip in a wide range of interrupting ratings (kaic).

Brand: LS ELECTRIC

Product Series: UTE100

Interrupting Capacity: 20 kaic (480VAC)

Supplied Connections: Load Lugs

Current Rating: 50A

Trip Unit: Fixed Themal/Fixed Magnetic

Poles: 2 Pole

Dimensions: 5.12 in H x 2.01 in W x 3.44 in D

SPECIFICATIONS

SPECIFICATIONS

Brand: LS ELECTRIC

Product Series: UTE100

Interrupting Capacity: 20 kaic (480VAC)

Supplied Connections: Load Lugs

Current Rating: 50A

Trip Unit: Fixed Themal/Fixed Magnetic

Poles: 2 Pole

Dimensions: 5.12 in H x 2.01 in W x 3.44 in D
